A constant temperature shrinking machine is a device that uses hot air with temperature control function to shrink items. Its working principle is to circulate constant temperature hot air between the heat shrink film and the packaging material through a fan, and complete the shrinkage through high temperature shaping. Compared to thermal cycle shrinking machines, constant temperature shrinking machines are more precise in temperature and hot air pressure control, which can make the shrinking effect more even and suitable for packaging large-sized items.

The characteristics of a constant temperature shrinkage machine include:

1. Temperature control: The constant temperature shrinking machine has temperature control function, which can ensure the stability and accuracy of the hot air temperature.
2. Pressure control: Achieve uniform shrinkage effect through precise hot air pressure control.

3. Scope of application: Suitable for packaging large-sized items, providing better protection and aesthetic packaging effects.


Technical characteristics:
1. Famous original controller, stable performance;

2. Electronic governor can arbitrarily adjust the speed of the conveyor belt;
3. Double-layer heat insulation device, the machine appearance will not be too hot;

4. Imported high temperature resistant cord, greatly reduce heat loss;

5. The use of stainless steel heater, high-power air motor, so that the shrinkage furnace heating block air volume, uniform air, according to the size of the product, product height can adjust the conveyor belt speed and furnace chamber temperature, in order to achieve the best shrinkage effect.

Thermostatic shrinking machines are widely used in various occasions that require large-sized packaging, such as furniture, hardware, electronic products, and other industries. Due to its uniform shrinkage effect and precise temperature control, it can better protect large-sized items and prevent damage during transportation.


TY-4525B Shrinking Machine
Mechanical Dimension L1500*W760*H1500mm
Cavity Size L1200*W450*H250mm
Maximum Package Size L700*W300*H200mm
Packing Speed 2000-2400
Belt Speed 0-20
Net Weight 195
Power supply/Power 3PH 380V 50Hz 1.2KW
